ZXTN2020FTA

Manufacturer Part	ZXTN2020FTA
Manufacturer	Diodes Incorporated
Description	TRANS NPN 100V 4A SOT23-3
Category	Discrete Semiconductor Products
RoHS	Lead free / RoHS Compliant
Warranty	365 days
Datasheet	-

Type	Description
Product Status:	Active
Transistor Type:	NPN
Current - Collector (Ic) (Max):	4 A
Voltage - Collector Emitter Breakdown (Max):	100 V
Vce Saturation (Max) @ Ib, Ic:	150mV @ 400mA, 4A
Current - Collector Cutoff (Max):	20nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:	100 @ 1A, 2V
Power - Max:	1.2 W
Frequency - Transition:	130MHz
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	TO-236-3, SC-59, SOT-23-3
Supplier Device Package:	SOT-23-3
