6437288-2

6437288-2

Manufacturer Part 6437288-2
Manufacturer TE Connectivity AMP Connectors
Description CONN HEADER R/A 34POS 3MM
Category Connectors, Interconnects
RoHS Lead free / RoHS Compliant
Warranty 365 days
Datasheet -
GB-T-27922
ISO-9001-2015
ISO-13485
ISO-14001
ISO-28000-2007
ISO-45001-2018
Product Attributes
Type Description
Product Status:Active
Connector Type:Receptacle
Contact Type:Male Pin
Pitch - Mating:0.118" (3.00mm)
Number of Positions:34
Number of Rows:4
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 4 Wall
Mounting Type:Through Hole, Right Angle
Termination:Solder
Fastening Type:Locking Ramp
Contact Length - Mating:-
Contact Length - Post:0.157" (4.00mm)
Overall Contact Length:-
Insulation Height:1.079" (27.40mm)
Contact Shape:Circular
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:-
Contact Finish - Post:Tin
Contact Material:Brass
Insulation Material:Polyester
Features:Mounting Flange, Sealed
Operating Temperature:-40°C ~ 125°C
Ingress Protection:-
Material Flammability Rating:-
Insulation Color:-
Current Rating (Amps):Varies by Wire Gauge
Voltage Rating:250V
